Feature
· 12um uncooled infrared detector, NETD≤35mk;
· 1024*768 resolution with 0.39-inch OLED display;
· AI-based automatic target recognition function
· Stable and reliable automatic target tracking function
· Various pseudo colors for different scenarios;
· Intelligent ballistic function
· Compact size and light weight
Specifications
Infrared module | |
Image Sensor | UFPA (VOx) |
Resolution | 384×288 |
Pixel pitch | 12µm |
Frame rate | 50Hz |
NETD | ≤35mk |
Spectral range | 8-14µm |
Optical parameter | |
Focal length / Aperture | 50mm; F1.0 |
Field of view | 7.2°×5.8° |
Focus Mode | Manual |
Eye relief / Exit pupil | 50mm / 6mm |
Diopter | +5D to -5D |
Detection Range | 2.6km (vehicle) |
Image Display | |
Screen | AMOLED, 0.39 inch |
Resolution | 1024×768 |
Eye relief | 50mm |
Exit pupil | 6mm |
Brightness Adjustment | Support |
Color Palette | White Hot/Black Hot/Red Hot/Fusion/Golden Hot etc. |
Digital Zoom | 1×; 2×; 4× |
Power supply | |
Battery type & number | 2 Lithium batteries |
Battery parameter | 18650（3400mah） |
External power supply | DC 5V (USB Type-C) |
Power Consumption | ≤2.2W（25℃） |
Battery Operating time | ≥10h （25℃） |
Electronic compass | Support |
Attitude sensor | Support |
WIFI / Bluetooth | Support; 2.4G |
Storage | Built-in EMMC (32GB) |
GPS | Support (Optional) |
Distance Measurement | Laser，905nm |
Ranging distance & accuracy | 1Km; ±1m |
General |
|
Interface | USB (Type-C) |
Protection level | IP67 |
Operating temperature | -30°C to +60°C |
Max. Recoil | 1200g/0.4ms |
Weight（without battery） | ≤890g |
Dimension | 245×60×90（mm） |
Scenario-Based Content
- Precision at Distance | Eliminate the Guesswork
Long-range shots require precision. The built-in 1000m Laser Rangefinder feeds accurate distance data to the onboard computer, instantly calculating bullet drop for your specific caliber.
- Smart Investment
Get flagship 50mm lens performance and LRF capabilities without the premium price tag of a 640 sensor. Perfect for hunters who prioritize identification range over wide field of view.
FAQ
Q: Why is the Field of View narrower than the 35mm model?
A: The 50mm lens provides higher optical magnification (narrower 7.2° FOV), which brings distant targets "closer" visually. This is intentional design for long-range shooting where target detail is more important than situational awareness.
Q: Is 384 resolution enough for 50mm lens?
A: Absolutely. The 12μm pixel pitch ensures a crisp image. Because the lens optically magnifies the image, you rely less on digital zoom, keeping the image sharp even at longer distances.
